    Cold Water Pressure Washer

    HDR-K 90-20

    Robust and very powerful with up to 200 bar, even in continuous operation in professional and commercial use

    1.695,00 EUR excl. Tax / pc(s).
    2.017,05 EUR incl. 19% Tax / pc(s).
    Promotional price *
    1.399,00 EUR excl. Tax / pc(s).
    1.664,81 EUR incl. 19% Tax / pc(s).

    Prices are recommended retail prices. Retailer prices may vary.
    * Promotional price valid until 31.08.2024 in Germany.

    Art.-No. 7102902

    Are you interested in this product?
  • Put a request
  • Find Trader

    • Productdetails

    • Mobile model with robust transport trolley and handle
    • Integrated detergent tank with simple detergent dosage
    • Adjustable working pressure for adaptation to the respective cleaning task, display of the set pressure via a pressure gauge
    • Fatigue- and wear-reducing Total Stop Timed pump control: Start and stop of the pump motor with soft start during operation and forty-second delayed switch-off, control by opening and closing the gun - your benefit: Low-fatigue operation with fewer pressure surges, no overheating of the pump due to frequent switching on and off, increased service life of all components
    • Long service life thanks to three-piston axial pump with connecting rod crank system and brass head, ceramic piston
    • Increased service life of the pump head thanks to automatic safety valve, oil level indicator and oil dipstick
    • 4-pole and slow-running durable electric motor for intensive use
    • Motor cooling fan and motor protection switch protect the induction motor from thermal overload
    • High-quality threaded connections
    • Easy to check and maintain water filter to protect the pump from dirt particles in the water
    • Integrated storage option for nozzle set
    • Practical holders for hand spray gun, jet pipe, high-pressure hose and mains cable
    • Interchangeable nozzle attachments for different spray angles
    • Made in Europe quality
    • Can be operated with a water tank or similar - The HDR-K is self-priming down to a depth of 0.5 m.



    • Very robust 3-piston axial pump with brass head and low-wear ceramic pistons
    • Powerful in continuous operation
    • Fatigue and wear-resistant work due to Total Stop Timed pump control
    • High quality threaded connections
    • Quality Made in Europe



    Dimensions and weights
    Length approx.670 mm
    Width/depth approx.540 mm
    Height approx.900 mm
    Weight approx.61.6 kg
    Electrical Data
    Input power7.4 kW
    Connection cable length5 m
    Supply voltage400 V
    Mains frequency50 Hz
    Noise emission
    Sound pressure level82.3 dB(A)
    Pump
    Working pressure185 bar
    Max. pump pressure215 bar
    Flow rate max900 l/h
    Operating positionstanding
    Water connection
    Max water inlet temperature60 °C
    VPE1
    Unit: pc(s).
    Packaging unit: 1

    • Trigger gun
    • lance
    • 5-part quick change nozzle set (spot beam 0 °, fan beam 15 ° / 25 ° / 40 °, foam application)
    • Nozzle cleaning needle
    • Water connection set with filter
    • Integrated detergent tank
    • Integrated, lockable hose reel with hand crank
    • 10 m high-pressure hose



    Cylinder head materialBrass
    PistonCeramics
    Pump controlTotal Stop Timed
    Self-priming pump✔
    Cleaning agent tank3 l
    Cleaning agent regulation✔
    High pressure hose pressure bearingSteel reinforcement
    High pressure hose length10 m
    Water filter✔
    Working pressure regulated✔
    Pressure gauge for working pressure ✔
    Integrated hose reel ✔
    Hose connection pump outlet Screw connection M22x1,5
    Hose connection manual spray gunScrew connection M22x1,5
    Wheels300 mm
