    Drilling-milling machine

    OPTImill MB 4SVD

    Universal precision drilling and milling machines with servo drive - SVD model with DRO 6 digital readout and magnetic measuring system

    4.469,00 EUR excl. Tax / pc(s).
    5.318,11 EUR incl. 19% Tax / pc(s).

    Prices are recommended retail prices. Retailer prices may vary.

    Sicherheits- und Warnhinweise

    Safety and warning notices

    Art.-No. 3338459

    Are you interested in this product?
  • Put a request
  • Find Trader

    • Productdetails

    • Precisely processed
    • Thread cutting function
    • Servo drive
    • Solid and generously dimensioned cross table, precisely surface-finished with T-slots and adjustable gibs
    • Adjustable end stops
    • Stable dovetail guide with adjustable gibs
    • Right-left rotation
    • LED machine light
    • Fine feed
    • Emergency stop switch
    • Drilling/milling head can be tilted by ±45
    • Height-adjustable protective screen with microswitch against flying chips and parts, for maximum protection of the user



    Data sheets
    Sicherheits- und Warnhinweise
    Safety and warning notices
    Dimensions and weights
    Length approx.1155 mm
    Width/depth approx.980 mm
    Height approx.1360 mm
    Weight approx.320 kg
    Drilling/milling head
    Mill head swivel range± 45 °
    Drilling/milling output
    Max. size milling head63 mm
    Max. size shaft milling cutter26 mm
    Drilling performance steel (S235JR)32 mm
    Continuous drilling performance steel (S235JR)28 mm
    Electrical Data
    Supply voltage230 V
    Mains frequency50 Hz
    Milling table horizontal
    Table length800 mm
    Table width240 mm
    T-groove size14 mm
    T-groove number3
    T-groove spacing63 mm
    Travel
    X axis manual450 mm
    Y axis manual200 mm
    Max. distance spindle to column275 mm
    Vertical spindle
    Spindle chuckMK 4 / MK 16
    Speed range60 3000 min¯¹
    Number of gears2
    Speed controlelectronically adjustable
    Drive motor output continuous operation S13 kW
    Quill stroke120 mm
    VPE1
    Unit: pc(s).
    Packaging unit: 1

    • Adapter MK4/MK 3
    • Tightening rod M 16
    • Adapter MK4/22 mm
    • Operating tool
