Air conditioner
SC-K 5300 D
Mobile device with integrated thermostat for the optimum cooling solution
2.499,00
EUR excl. Tax / pc(s).
2.973,81 EUR incl. 19% Tax / pc(s).
2.973,81 EUR incl. 19% Tax / pc(s).
Promotional price *
2.349,00 EUR excl. Tax / pc(s).2.795,31 EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 31.08.2025 in Germany.
Art.-No. 6550015
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Three-channel spot cooler for rapid spot and room cooling
- Flexible cooling thanks to three tilting and swiveling cold air ducts
- Cooling down to 0 °C possible thanks to adjustable mode
- Easy to maneuver thanks to compact design and castors with parking brake
- Integrated thermostat with digital display of set and actual temperature
- Cable winding device keeps cables tidy without the risk of tripping
- Suitable for cooling applications in workshops, network rooms, commercial kitchens and other environments
- Robust sheet steel construction
- Fill level warning light and warning signal when condensate container is full
- Use of environmentally friendly refrigerant R-1234yf
- No preliminary installation work, can be used immediately
- Additional functions: Dehumidification function, Ventilation function, Room air cooling, Spot cooling mode, Compressor protection, Overheating protection, Automatic defrosting, Automatic fault diagnosis, Sensor-controlled temperature display
- Three-channel spot cooler for rapid spot and room cooling
- Flexible cooling thanks to three tilting and swiveling cold air ducts
- Easy to maneuver thanks to compact design and castors with parking brake
- Integrated thermostat with digital display of set and actual temperature
- Fill level warning light and warning signal when the condensate container is full
- Use of environmentally friendly refrigerant R-1234yf
| Cooling capacity (kW) | 5.3 kW |
| Air volume Stage max. | 800 m³/h |
| Number of fan stages | 2 |
| Radial fan | 1 |
| Axial fan | 1 |
| Achievable room temperature | 0 °C |
| Temperature min. | 18 °C |
| Temperature max. | 45 °C |
| Recommended room volume | 50 – 102.5 m³ |
| VPE | 1 |
| Compressor | |
|---|---|
| Refrigerant type | R1234yf |
| Refrigerant quantity | 950 g |
| GWP factor | 4 |
| CO2 equivalence | 0.0008 t |
| Suction side pressure | 1 Mpa |
| Pressure outlet side | 2.5 Mpa |
| Dimensions and weights | |
|---|---|
| Length approx. | 560 mm |
| Width/depth approx. | 620 mm |
| Height approx. | 1135 mm |
| Weight approx. | 95 kg |
| Electrical Data | |
|---|---|
| Rated current consumption (cooling) | 10 A |
| Power consumption (cooling) | 2.2 kW |
| Connector plug | CEE 7/7 |
| Cable length | 1.9 m |
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
| Exhaust air | |
|---|---|
| Total length of exhaust air hose for cold air | 350 mm |
| Outer diameter of exhaust air hose for cold air | 120 mm |
| Outer diameter connection for hot air | 730 mm |
| Number of exhaust air connections | 3 |
| Noise emission | |
|---|---|
| Sound power level LWA | 75 dB(A) |
| Sound pressure level LpA | 65 dB(A) |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
| Condensate water tank | 25 l |
| Room thermostat | ✔ |
| Transport rollers | ✔ |
| Transport handles | ✔ |
