Productdetails
- Compressor design with movable piston on the connecting rod forr high efficiency and long service life
- very smooth running and extremely quiet
- long service life due to low speed
- Maximum mechanical efficiency
- No transmission elements
- Air flows directly through the cylinder for effective cooling
- Highly efficient cooling air fan
- front and additional cooling for maximum durability
- reed valves for optimum efficiency
- anti-corrosive surface treatment
- Air flows directly through the cylinder and provides effective cooling
- Very smooth running and extremely quiet
- Low speed and thus long service life
- Compressor design with movable piston on connecting rod for high efficiency and long service life
Type | Three-phases oil-free |
Maximum pressure | 10 bar |
Number of cylinders | 4 |
Number of compressor stages | 1 |
Suction capacity approx. | 440 l/min |
Filling capacity approx. | 267 l/min |
Explanation filling capacity | at 6 bar working pressure |
Speed | 1400 min¯¹ |
Drive transmission | Direct-coupled |
VPE | 1 |
Compressed air tank |
---|
Maximum pressure | 10 bar |
Compressor |
---|
Suction capacity approx. | 440 l/min |
Filling capacity approx. | 267 l/min |
Explanation filling capacity | at 6 bar working pressure |
Number of cylinders | 4 |
Number of compressor stages | 1 |
Dimensions and weights |
---|
Length approx. | 600 mm |
Width/depth approx. | 380 mm |
Height approx. | 310 mm |
Weight approx. | 47 kg |
Electrical Data |
---|
Delivery power | 1.7 kW |
Delivery power | 1.7 kW |
Absorbed power | 2,2 kW |
Supply voltage | 400 V |
Mains frequency | 50 Hz |
Noise emission |
---|
Sound pressure level Lp | 70 dB(A) |
Sound pressure level Lp | 70 dB(A) |
Unit: pc(s).
Packaging unit: 1
Aftercooler | ✔ |
High-quality connecting rod bearings | ✔ |
Cylinder made of aluminium | ✔, with special surface treatment |
Overload protection | ✔ |
Start-up relief valve | ✔ |
Drive transmission | Direct-coupled |
Connection cable | 1,8 m |
