    Screw compressor

    K-MAX 15-08-500 ES VS (IE3)

    Compact screw compressor with variable speed control and innovative LOGIN control system

    16.950,00 EUR excl. Tax / pc(s).
    20.170,50 EUR incl. 19% Tax / pc(s).

    Prices are recommended retail prices. Retailer prices may vary.

    Sicherheits- und Warnhinweise

    Safety and warning notices

    Art.-No. 2965972.2

    Are you interested in this product?
  • Put a request
  • Find Trader

    • Productdetails

    • Innovative LOGIN control with 4.3" touch screen for easy operation and complete control over all functions
    • Connection of up to eight compressors possible, no matter if with constant or variable speed
    • All information on current operating status at a glance
    • Rotation direction control for the motor, prevents damage during start-up or after a change of location
    • Low noise emission (only max. 67 dB) during operation, due to extremely low speed of the screw compressor and use of a low-noise radial fan
    • Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
    • Aftercooler reduces the effort for drying and filtration of the generated compressed air
    • Service-friendly: easy removal and installation of all components requiring maintenance

    Energy saving through frequency control

    • Ideal for frequently changing compressed air consumption
    • Compressor delivery rate adjusts to actual consumption
    • Electronic control monitors motor and compressor speed and keeps line pressure constant even when consumption fluctuates widely



    Data sheets
    Data sheet measurement
    Sicherheits- und Warnhinweise
    Safety and warning notices
    Effective delivery quantity of up to approx.950 2500 l/min
    Maximum Pressure8 bar
    Air outlet3/4 "
    Oil-free / oil-lubricatedOil lubricated
    Mobile / StationaryStationary
    VPE1
    Compressed air tank
    Pressure vessel capacity500 l
    Dimensions and weights
    Length approx.2000 mm
    Width/depth approx.730 mm
    Height approx.1660 mm
    Weight approx.435 kg
    Electrical Data
    Motor power (input power) electric motor15 kW
    Supply voltage400 V
    Mains frequency50 Hz
    Noise emission
    Sound pressure level Lp67 dB(A)
    Explanation sound pressure level LpSound pressure level at a distance of 1 m according to DIN 45635 T 13
    Unit: pc(s).
    Packaging unit: 1







    Frequency controlled✔
    ControlElectronical
    Oil heat exchanger✔
    Compressor typeFS50

    If a guarantee is shown in the article description and/or in the description of the scope of delivery, your legal rights of liability for defects towards your seller remain unaffected. For the scope, duration, content and the guarantor, please refer to the guarantee conditions. We are not liable for printing errors, mistakes or incorrect presentation. Technical and optical changes are reserved. Fig. partly with optional accessories. Delivery is made exclusively according to our terms of delivery and payment. The sale is carried out via the specialized trade.
