Activated carbon filter
CLEARPOINT® 3eco S040 AWM
An innovative concept, convincing in detail
190,00
EUR excl. Tax / pc(s).
226,10
EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
Art.-No. 2046067
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Flow-optimized air supply for up to 75% less resistance
- Assembly of the filter elements without cross-sectional narrowing and disturbing tie rods, thus reduced flow resistance and easy element change even in confined spaces
- Cavity volume of the borosilicate filter material of 96% ensures the lowest pressure loss
- CLEARPOINT® filter housing made of water-resistant aluminum and additionally anodised on the inside, therefore increased operational safety and reduced flow resistance due to permanently smooth inner surfaces
- 100% control when opening the filter housing by a secure locking mechanism, when opened under pressure a warning signal sounds
- With thermally highly resistant (up to 120 ° C), mechanically highly resistant, chemically resistant and silicone-free needle felt drainage layer (in contrast to foam material of other filter makes)
- Stable construction of the filter element - it is not possible to inflate or rupture the drainage layer, thereby ensuring the constant use of the entire filter surface
- for the separation of oil vapors, odors and flavorings via adsorption and in the second stage of solid particles
- Residual content of oil vapor up to 0.003 mg / m³ at 20 ° C and 1 bar
- absolute compressed air quality according to ISO 8573-1
- For compressed air of the highest quality, eg, for breathing air, in analytical technology or semi-luxury bottling
- Pure compressed air in connection with upstream ultrafine filter
- With filter element and manual drain
| Volume flow m³/h | 35 test |
| Volume flow l/min | 580 l/min |
| Volume flow measured at operating pressure | 7 bar |
| Air connection | 3/8 " |
| VPE | 1 |
| Dimensions and weights | |
|---|---|
| Width/depth approx. | 75 mm |
| Height approx. | 180 mm |
| Technical data | |
|---|---|
| Operation | Safe segregation of oil vapours, taste and odor-producing substances by adsorption and of solid particles in second step |
| Range of Application | For highest quality compressed air, e.g. for breathing air, laboratories, or food processing industry |
| Particle size | 1 µm |
| Residual oil vapor content | 0.003 mg/m³ |
| Comment on residual content | at 20°C and 1 bar |
| Differential pressure (dry) | 0.07 bar |
| Purity class of compressed air in accordance with ISO 8573-1 | 1.–.1-2 |
| Comment on purity class | Pure compressed air in connection with upstream superfine filter. Attention: Filter element has to be replaced after 300 operating hours |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
Filter element, manual valve
