Motorized plate rolling machine
RBM 2050-30E Pro
In heavy design for sheet thicknesses up to 4 mm
13.599,00
EUR excl. Tax / pc(s).
16.182,81 EUR incl. 19% Tax / pc(s).
16.182,81 EUR incl. 19% Tax / pc(s).
Promotional price *
12.999,00 EUR excl. Tax / pc(s).15.468,81 EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 31.08.2025 in Germany.
Art.-No. 3813303
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Heavy welded steel construction
- top and clamping roller driven
- Swing-out top roller
- Manual adjustment of the clamping and side roller
- Roller drive via powerful electric motor and gearbox
- Wire grooves on the clamping roller
- Safety device emergency stop line
- With mobile control panel and foot pedal
- Note: Please specify the type of material to be processed when ordering!
- Note: Other models on request
Equipment details:
- Swing-out top roller
- Control panel with digital display and manual operation (optional)
- RBM 2050-30 E PRO with optional motorized infeed of the side roller and digital display for side roller
| Bending performance | |
|---|---|
| Max. bending performance in steel 400 N/mm²² | 3.0 mm |
| Max. taper bending performance in steel 400 N/mm² | 1.5 mm |
| Max. bending performance in stainless steel | 2.25 mm |
| Max. taper bending performance in stainless steel | 1.1 mm |
| Max. bending performance aluminium | 3.6 mm |
| Max. taper bending performance in aluminium | 1.8 mm |
| Min. bending diameter | 195 mm |
| Roller speed | 3.5 m/min |
| Dimensions and weights | |
|---|---|
| Max. working width | 2050 mm |
| Top roller diameter | 130 mm |
| Length approx. | 3200 mm |
| Width/depth approx. | 750 mm |
| Height approx. | 1000 mm |
| Weight approx. | 1500 kg |
| Electrical Data | |
|---|---|
| Drive motor output | 2,2 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
| Top roller | driven, swing-out |
| Bottom roller | driven |
| Wire insert groove | on the clamping roller |
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
Deutschland / Germany
info@stuermer-maschinen.de
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
Deutschland / Germany
info@stuermer-maschinen.de
If a guarantee is shown in the article description and/or in the description of the scope of delivery, your legal rights of liability for defects towards your seller remain unaffected. For the scope, duration, content and the guarantor, please refer to the guarantee conditions. We are not liable for printing errors, mistakes or incorrect presentation. Technical and optical changes are reserved. Fig. partly with optional accessories. Delivery is made exclusively according to our terms of delivery and payment. The sale is carried out via the specialized trade.
Optional parts
Optional parts can not be retrofitted and are available only when ordering new machines.
