    Electric tap

    GS 18

    With reverse gear for time-saving, precise cutting of threads in boreholes

    645,00 EUR excl. Tax / pc(s).
    767,55 EUR incl. 19% Tax / pc(s).
    Promotional price *
    579,00 EUR excl. Tax / pc(s).
    689,01 EUR incl. 19% Tax / pc(s).

    Prices are recommended retail prices. Retailer prices may vary.
    * Promotional price valid until 31.08.2025 in Germany.

    Sicherheits- und Warnhinweise

    Safety and warning notices

    Art.-No. 3860018

    Are you interested in this product?
  • Put a request
  • Find Trader

    • Productdetails

    • Reversing gear allows a very short processing time: pressure on the spindle starts the slow clockwise rotation of the tool, when retracting the fast rewind is automatically activated at 680 rpm
    • Easy tapping in just one operation due to high torque, low speed and high concentricity
    • Additional handle allows optimal and comfortable tool guidance
    • Compensation of angular misalignment of the cutting tool in the bore by a joint between food intake and threaded chuck
    • Standard depth stop for blind hole drilled holes



    • Reversing gears for quick and easy thread cutting
    • Precision due to high torque, low speed and high concentricity
    • Universal mount with slip clutch for longer life of the workpiece
    • Compensation of angular misalignment of the tool due to the universal joint



    Data sheets
    Sicherheits- und Warnhinweise
    Safety and warning notices
    Dimensions and weights
    Explanation about DimensionsAdditional handle at 90° position to the handle
    Length approx.400 mm
    Width/depth approx.325 mm
    Height approx.240 mm
    Weight approx.3.15 kg
    Drive output
    Absorbed power drive motor0.45 kW
    Electrical connections
    Connection cable length3 m
    Electrical Data
    Supply voltage230 V
    Mains frequency50 Hz
    Speed range
    Idle (CW run)280 min¯¹
    Idle (CCW run)680 min¯¹
    Speed(s) under load170 min¯¹
    Under load (CCW run)410 min¯¹
    Thread tapping
    Steel (S235JR) short-term operationM18
    Steel (S235JR) continuous operationM14
    Aluminium short-term operationM18
    Aluminium continuous operationM16
    VPE1
    Unit: pc(s).
    Packaging unit: 1

    • Universal mount M6 - M18 with slip clutch
    • Auxiliary handle
    • depth stop
    • 4 mm hex key
    • Carrying case
