Max. cutting height | 330 mm |
Saw band speed(s) | 15 – 120; 190 – 1500 m/min |
Saw band length | 4990 mm |
Max. saw band length | 5030 mm |
Saw band width | 13 – 27 mm |
Saw band thickness | 0,65 – 0,9 mm |
Reach | 915 mm |
Table length | 600 mm |
Table width | 700 mm |
Table load max. | 350 kg |
Extension table length | 450 mm |
Extension table width | 700 mm |
Working height | 990 mm |
Table swivel range for mitre cuts | 12 / 12 ° |
Saw band welding device output | 19 mm |
Wheel diameter | 515 mm |
Diameter of additional top wheel | 368 mm |
Sound pressure level | 73.2 dB(A) |
VPE | 1 |
