Table press
System 22
Perfect welded construction by preloading before welding
1.073,00
EUR excl. Tax / pc(s).
1.276,87
EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
Art.-No. 193220780
Are you interested in this product?
Put a request
Find Trader
Productdetails
The table press is used for straightening deformed steel products. With a pressing force of 2.5 tons, parts that have unwanted unevenness or tension in the material can be straightened. With the additionally available pipe bending punch, pipes with a diameter of up to 42 mm can be flexibly bent.
The total stroke is 60 mm, which can be achieved with 13 pump strokes with an operating force of approx. 330 N (stroke per pump stroke 4.6 mm). An overflow valve prevents further pressure build-up when the piston rod is fully extended.
For secure mounting on the table, the table press can be fixed by the turret either with quick-action clamping bolts or by the machined-on bolt.
The table press must always be fixed in two places.
| Dimensions and weights | |
|---|---|
| Weight approx. | 6.7 kg |
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
